20K – 30K Helical Drive Head

PierTech's™ Standard Helical Drive Heads were designed specifically for helical pier or pile installation. Designed by real-world engineers who understand the demands of the foundation industry, these drive heads are designed to perform under the most strenuous environments. Their design also allows them to run at the highest efficiency rates so that they will perform dependably for years.

Get a Quote

Feature

Key Features

Piertech™

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Sit lacus non nec rhoncus leo aliquam porttitor massa. Pellentesque magna ornare tempor cras rutrum non mauris convallis.

See It In Action

More Torque Less Pressure

Two pressure series are available to suit your requirements:

01

Standard pressure series for machines with 3500 PSI (ADS range)

02

Low pressure series, for machines with 3000 PSI (ALS range)



Specifications

Product Specifications

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Sit lacus non nec rhoncus leo aliquam porttitor massa. Pellentesque magna ornare tempor cras rutrum non mauris convallis.

Description 20ADS 25ADS 30ADS 20ALS 25ALS
NOMINAL TORQUE (FT LBS) 19,488 24,514 30,771 21,012 26,375
MAX PRESSURE – DO NOT EXCEED 3500PSI @ 33 GPM 3500PSI @ 33 GPM 3500PSI @ 33 GPM 3000PSI @ 33 GPM 3000PSI @ 33 GPM
MAX FLOW – DO NOT EXCEED 61 GPM @2200 PSI 61 GPM @2200 PSI 61 GPM @2200 PSI 61 GPM @2200 PSI 61 GPM @2200 PSI
MAX HORSE POWER 67 67 67 67 67
PRESSURE RELIEF VALVE INCLUDED INCLUDED INCLUDED INCLUDED INCLUDED
INERTIA CONTROL VALVE INCLUDED INCLUDED INCLUDED INCLUDED INCLUDED
STANDARD OUTPUT SHAFT 100mm Square 100mm Square 100mm Square 100mm Square 100mm Square
WEIGHT (LBS) 640 LBS 640 LBS 640 LBS 640 LBS 640 LBS
OVERALL LENGTH (IN) 45.3" 45.3" 45.3" 45.3" 45.3"
DIAMETER (IN) 14" 14" 14" 14" 14"
Get a Quote

To find out more about our hand-held helical drives, please contact our equipment advisors.
